Element replacement
• Remove the cover from the inner drum.
• Removed nuts, washers and clamps through the
cover opening in the inner drum.
• Undo the nut on the middle screw of the element
and turn the screw 1/4 of a turn. The
counterweight on the inside is now in a position
to permit the element to be withdrawn.
• Insert a new element, turn the centre screw a
1/4 turn and tighten the nut.
• Fit clamps, washer and nut through the opening
in the inner drum.
• Fit the cover to the inner drum.
• Check that there are no burns on the screw
head or the cover.
• Connect element. NOTE: Earthing!
• Check there is no leak by the element and reset
machine.
40
2
40. Heating
