Electrolux FLE220 - Page 30

12. Function Sequences Edition
Type
Service
Manual
17 9108
12
Page
1680
15
A : Power supply: see ''Power supply and
start'' sequence
(1) Programmer, row M, stop
(2) Speed control B31
(3) Relay K31, drain
(4) Switch S33 (gentle action)
(5) Reverser row 1
(6) Reverser row 2
(7) Relay coil K2, wash
(8) Motor M22 Reverser
D : Power supply: see ''Power supply and
start'' sequence
M
M
B31
K31
S33
1
2
K2
M22
A
3
2
1
X31:1
1
2
X31:2
52
51
2
1
b
b
4
61
57
56
D
58
59
A1
A2
62
63
