Removing drawer rail from range frame:
1. Remove the screw holding the rail to the frame and
pull forward on the rail.
Rail screw
Removing warmer drawer low limit thermostat:
1. Disconnect power from range.
2. Remove wires from back of thermostat.
3. Remove the two screws holding the thermostat to
the bracket and pull the thermostat forward.
Warmer drawer thermostat screws
Removing the warmer drawer element:
1. Disconnect power from range.
2. Remove wires from the element.
3. Remove the two screws holding the element to the
bracket and the four screws holding the element to
the base. Pull the element forward out of the bracket.
Warmer drawer element screws
