Electrolux t4130c - Component Locations

8
2
3
1
5
5
5
6
2
Description of principal components
Service
manual
14
1. B1 Connection terminal
2. Ext Connection max.
1,25A 200-240V AC
3. TR1 Transformer
4. K4 Contactor, heat
5. Cn X/Y Capacitor
6. RC RC unit
7. C Motor operating capacitor
8. F10 Fuse T 2.5 A
9. PCB1 Selecta II
1. B1 Connection terminal
2. TR1 Transformer
3. K4 Contactor, heat
4. Cn X/Y Capacitor
5. RC RC unit
6. PCB1 Selecta II
200-240V 3 AC
400-415V 3 AC + N
400-480V + 3 AC
without N
1
5
6
7
9
4
3
