18
Installation manual
3.3.3 Chemical anchors
If installation shall be done on vinyl floor coverings chemical anchors shall be used.
1. Mark and drill four holes for the chemical anchors.
Check the previous table for the correct position of the holes.
2. Cut the flooring material around the washers
3. Apply sealant to the hole cut in the vinyl floor covering. Insert the washer. Use sealant to seal around the washer
between the vinyl and the washer.
4. Put the machine into place.
Check that the machine is in level. If it is not, use spacers where required between floor and machine.
If chemical anchors are used, do not use the nut and washer supplied with them.
Fix the machine in place using the washers and nuts supplied with the machine.
5. Installation with mounting frame.
fig.7644
