Electrolux W3 SERIES Installation Manual

30
Installation manual
8.2 Electrical connections
W575N
Heating alternative Main voltage Hz Heating power
kW
Total power
kW
Recommended fuse
A
Electric heated 220-240V 1 ~ 50/60 5.4/7.5 5.7/7.8 25/35
220-240V 1 ~ 50/60 2.0/3.0 2.3/3.3 16
220-240V 3 ~ 50/60 5.4/7.5 5.7/7.8 16/25
380-415V 3N ~ 50/60 5.4/7.5 5.7/7.8 10/16
440V 3 ~ 60 7.5 7.8 16
480V 3 ~ 60 7.5 7.8 16
Non heated/Steam
heated
220-480V 1 ~ 50/60
-
0.4 10
W585N
Heating alternative Main voltage Hz Heating power
kW
Total power
kW
Recommended fuse
A
Electric heated 220-240V 1 ~ 50/60 5.4/7.5 5.7/7.8 25/35
220-240V 1 ~ 50/60 2.0/3.0 2.3/3.3 16
220-240V 3 ~ 50/60 5.4/7.5 5.7/7.8 16/25
380-415V 3N ~ 50/60 5.4/7.5 5.7/7.8 10/16
440V 3 ~ 60 7.5 7.8 16
480V 3 ~ 60 7.5 7.8 16
Non heated/Steam
heated
220-480V 1 ~ 50/60
-
0.4 10
W5105N
Heating alternative Main voltage Hz Heating power
kW
Total power
kW
Recommended fuse
A
Electric heated 220-240V 1 ~ 50/60 3.0/7.5/10.0 3.3/7.8/10.3 20/35/50
220-240V 3 ~ 50/60 7.5/10.0 7.8/10.3 25/35
380-415V 3N ~ 50/60 7.5/10.0 7.8/10.3 16/20
440V 3 ~ 60 7.5/10.0 7.8/10.3 16
480V 3 ~ 60 7.5/10.0 7.8/10.3 16
Non heated/Steam
heated
220-480V 1 ~ 50/60
-
0.8 10
W5130N
Heating alternative Main voltage Hz Heating power
kW
Total power
kW
Recommended fuse
A
Electric heated 220-240V 1 ~ 50/60 3.0/7.5/10.0 3.5/8.0/10.4 20/35/50
220-240V 3 ~ 50/60 7.5/10.0 8.0/10.4 25/35
380-415V 3N ~ 50/60 7.5/10.0 8.0/10.4 16/20
440/480V 3 ~ 60 7.5/10.0 8.0/10.4 16
Non heated/Steam
heated
220-480V 1 ~ 50/60
-
1.0 10
W5180N
Heating alternative Main voltage Hz Heating power
kW
Total power
kW
Recommended fuse
A
Electric heated 220-240V 1 ~ 50/60 13.0 13.5 63
220-240V 3 ~ 50/60 13.0 13.5 35
380-415V 3N ~ 50/60 13.0 13.5 25
440V 3 ~ 60 13.0 13.5 20
480V 3 ~ 60 13.0 13.5 20
Non heated/Steam
heated
220-480V 1 ~ 50/60
-
1.0 10
