Installation manual
31
W5250N
Heating alternative Main voltage Hz Heating power
kW
Total power
kW
Recommended fuse
A
Electric heated 220-240V 3 ~ 50/60 18.0 18.8 50
380-415V 3N ~ 50/60 18.0 18.7 35
440V 3 ~ 60 18.0 18.8 35
480V 3 ~ 60 18.0 18.8 25
Non heated/Steam
heated
220-480V 1 ~ 50/60
-
1.1 10
Max. permitted impendance* = 0.26 Ohm
W5330N
Heating alternative Main voltage Hz Heating power
kW
Total power
kW
Recommended fuse
A
Electric heated 220-240V 3 ~ 50/60 19.8/23.0 21.0/24.2 63
380-415V 3 ~ 50/60 19.8/23.0 21.0/24.2 35/50
440V 3 ~ 60 21.0/23.0 22.2/24.2 35
480V 3 ~ 60 22.8/23.0 24.0/24.2 35
220-230V 3 ~ 50/60 19.1 20.3 63
380-400V 3 ~ 50/60 19.1 20.3 35
Non heated/Steam
heated
220-480V 1 ~ 50/60
-
1.4 10
Max. permitted impendance* = 0.26 Ohm
* The impendance in the mains connected point in accordance with EN31000–3–11. If the impendance in the mains
connected point is higher than stated, check with the power supplier.
