Electrolux W575HLE - Model-Specific Technical Data

Installation manual
11
3.2 Technical data
W565H/
W565HLE
W575H/
W575HLE
W5105H W5130H W5180H W5240H W5300H
Weight, net kg 145 158 202 263 354 425 560
Drum volume litres 65 75 105 130 180 240 300
Drum diameter
mm
520 520 595 650 725 795 795
Drum speed during wash
rpm
49 49 49 49 44 42 42
Drum speed during extraction
rpm
1245 1245 1165 1115 1055 1005 950
G-factor, max. 450 450 450 450 450 450 400
Heating: Electricity kW 2.0 2.0 5.2 13 18 23 23
kW 3.0 3.0 7.5
kW 5.2 5.2 10
kW 5.4 5.4
kW 7.5 7.5
Heating: Steam
x x x x x x x
Heating: Hot water
x x x x x x x
Frequency of the dynamic
force
Hz 20.8 20.8 19.4 18.6 17.6 16.8 15.8
Floor load at max extraction kN 1.8 ± 0.5 1.9 ± 0.5 2.5 ± 0.5 3.1± 0.5 4.2 ± 1.0 5.2 ± 1.0 6.2 ± 1.3
Sound power/pressure level at
extraction*
dB(A) 73/58 73/59 76/62 78/62 84/68 83/68 82/66
Sound power/pressure level at
wash*
dB(A) 57/43 61/47 61/46 63/48 66/50 64/48 66/50
* Sound power levels measured according to ISO 60704.
3.3 Connections
W565H/
W565HLE
W575H/
W575HLE
W5105H W5130H W5180H W5240H W5300H
Water valves DN
BSP
20
3/4”
20
3/4”
20
3/4”
20
3/4”
20
3/4”
20
3/4”
20
3/4”
Recommended water
pressure
kPa 200–600 200–600 200–600 200–600 200–600 200–600 200–600
Continuous operating
pressure
kPa 50–800 50–800 50–800 50–800 50–800 50–800 50–800
Capacity at 300 kPa l/min 20 20 20 20 30 60 60
Drain valve
⌀ outer
mm
50/75 50/75 50/75
75 75 75 75
Draining capacity l/min 170 170 170 170 170 170 170
Steam valve connection DN
BSP
15
1/2”
15
1/2”
15
1/2”
15
1/2”
15
1/2”
15
1/2”
15
1/2”
Recommended steam
pressure
kPa 300–600 300–600 300–600 300–600 300–600 300–600 300–600
Functioning limits for steam
valve
kPa 50–800 50–800 50–800 50–800 50–800 50–800 50–800
