Electrolux W575HLE - Machine Power Connections

Installation manual
27
9.2 Electrical connections
W565H, W565HLE
Heating alternative Main voltage Hz Heating power
kW
Total power
kW
Recommended fuse
A
Electric heated 220-240V 1 ~ 50/60 5.4/7.5 5.5/7.6 25/35
220-240V 1 ~ 50/60 2.0/3.0 2.1/3.1 16/16
220-240V 3 ~ 50/60 5.4/7.5 5.5/7.6 16/20
220-240V 3 ~ 50/60 3.0/4.3 3.1/4.5 10/16
380-415V 3N ~ 50/60 5.4/7.5 5.5/7.6 10/16
380-415V 3N ~ 50/60 3.0/4.3 3.1/4.5 10
440V 3 ~ 60 7.5 7.6 16
480V 3 ~ 60 7.5 7.6 16
Non heated/Steam
heated
220-480V 1/3 ~ 50/60
-
1.0 10
W575H, W575HLE
Heating alternative Main voltage Hz Heating power
kW
Total power
kW
Recommended fuse
A
Electric heated 220-240V 1 ~ 50/60 5.4/7.5 5.5/7.6 25/35
220-240V 1 ~ 50/60 2.0/3.0 2.1/3.1 16/16
220-240V 3 ~ 50/60 5.4/7.5 5.5/7.6 16/20
220-240V 3 ~ 50/60 3.0/4.3 3.1/4.5 10/16
380-415V 3N ~ 50/60 5.4/7.5 5.5/7.6 10/16
380-415V 3N ~ 50/60 3.0/4.3 3.1/4.5 10
440V 3 ~ 60 7.5 7.6 16
480V 3 ~ 60 7.5 7.6 16
Non heated/Steam
heated
220-480V 1 ~ 50/60
-
1.0 10
W5105H
Heating alternative Main voltage Hz Heating power
kW
Total power
kW
Recommended fuse
A
Electric heated 220-240V 1 ~ 50/60 3.0/7.5/10.0 3.3/7.8/10.3 16/35/50
220-240V 3 ~ 50/60 7.5/10.0 7.8/10.3 20/35
380-415V 3N ~ 50/60 7.5/10.0 7.8/10.3 16
440V 3 ~ 60 7.5/10.0 7.8/10.3 16
480V 3 ~ 60 7.5/10.0 7.8/10.3 10/16
Non heated/Steam
heated
220-480V 1 ~ 50/60
-
1.1 10
W5130H
Heating alternative Main voltage Hz Heating power
kW
Total power
kW
Recommended fuse
A
Electric heated 220-240V 1 ~ 50/60 4.8/13.0 5.3/13.3 25/63
220-240V 3 ~ 50/60 4.8/13.0 5.3/13.3 16/35
380-415V 3N ~ 50/60 4.8/13.0 5.3/13.3 10/20
440V 3 ~ 60 13.0 13.3 20
480V 3 ~ 60 13.0 13.3 20
Non heated/Steam
heated
220-480V 1 ~ 50/60
-
1.2 10
