Installation manual
4 Setup
4.1 Unpacking
4.1.1 W565H, W565HLE, W575H, W575HLE, W5105H
The machine is delivered complete with expander bolts, supporting feet etc.
The machine is delivered bolted onto the transport pallet and packed in a crate or box.
Remove packing from the machine.
Remove the front and rear panel.
Remove the four transport supports. Save the transport supports if the machine needs to be moved in the future.
Note!
Once the transport supports have been removed, handle the machine carefully to avoid damage to the sus-
pension components.
fig.X00841A
Remove the bolts between the machine and pallet. There is one to the right in the front of the machine and another
diagonally opposed to it, at the back of the machine.
fig.W00841B
