Installation manual
15
Remove the machine from the pallet.
Note!
When moving the machine, handle it with care.
Place the machine on its final position.
Mount the supporting feet.
W5300H: Note the position of the two front feet.
W5130H, W5180H, W5240H
W5300H
Remount the panels.
4.2 Siting
Install the machine close to a floor drain or open drain.
The machine should be positioned so that there is plenty of room for working, both for the user and service personnel.
The figure shows minimum distance to a wall and/or other machines.
fig.X00959
A 50 mm / 1 15/16 inch
B 500 mm / 20 inch
