28
Installation manual
W5180H
Heating alternative Main voltage Hz Heating power
kW
Total power
kW
Recommended fuse
A
Electric heated 220-240V 3 ~ 50/60 18.0 18.3 50
380-415V 3N ~ 50/60 18.0 18.3 35
440V 3 ~ 60 18.0 18.4 25
480V 3 ~ 60 18.0 18.4 25
Non heated/Steam
heated
220-480V 1 ~ 50/60
-
2.3 10
Max. permitted impendance* = 0.26 Ohm
W5240H
Heating alternative Main voltage Hz Heating power
kW
Total power
kW
Recommended fuse
A
Electric heated 220-240V 3 ~ 50/60 19.8/23.0 20.5/23.7 63
380-415V 3 ~ 50/60 19.8/23.0 20.5/23.7 35/35
440V 3 ~ 60 21.0/23.0 21.7/23.7 35
480V 3 ~ 60 22.8/23.0 23.5/23.7 35
220-230V 3 ~ 50/60 19.1 19.8 63
380-400V 3 ~ 50/60 19.1 19.8 35
Non heated/Steam
heated
220-240V 1 ~ 50/60
-
2.5 16
380-480V 1 ~ 50/60
-
2.5 10
230/400V 1 ~ 50
-
2.5 10
Max. permitted impendance* = 0.26 Ohm
W5300H
Heating alternative Main voltage Hz Heating power
kW
Total power
kW
Recommended fuse
A
Electric heated 220-240V 3 ~ 50/60 19.8/23.0 20.6/23.8 63
380-415V 3 ~ 50/60 19.8/23.0 20.6/23.8 35/50
440V 3 ~ 60 21.0/23.0 21.8/23.8 35
480V 3 ~ 60 22.8/23.0 23.6/23.8 35
220-230V 3 ~ 50/60 19.1 19.9 63
380-400V 3 ~ 50/60 19.1 19.9 35
Non heated/Steam
heated
220-240V 1 ~ 50/60
-
3.0 16
380-480V 1 ~ 50/60
-
3.0 10
230/400V 1 ~ 50
-
2.2 10
Max. permitted impendance* = 0.26 Ohm
* The impendance in the mains connected point in accordance with EN31000–3–11. If the impendance in the mains
connected point is higher than stated, check with the power supplier.
