3.2. Start Up
Info: E-COAT Master Powder Coating Control unit always starts with the last used conguration preferences.
In the above “System Connections” gure, all the electrical and pneumatic connections are shown. After correctly connecting the
device, the user can press the “Main Switch” to start the control unit. The below procedure should be done at the rst Start up.
E-COAT Master should be calibrated according to the products that are going to be powder coated before the start up. Once you
are in the “Main Page” Press the B1 interface button for 5 seconds and the Congurations Page 1 will appear a. The Conguration
Pages are ve pages in total and by pressing B2 button the user can cycle through them. The user can switch to the “Main Page”
by pressing B1 button once.
Info: If the control unit is not used or a button is not pressed for 15 seconds time, the control unit automatically goes
back to the “Main Page”.
The available calibrations for the “Calibration Pages” are stated in the below table
Code Code Info Preferences Factory Preset
C-1 Control Type Selection
0 = Automatic
1 = Manual w/ Hopper
2 = Manual w/ Multicolor
1
C-2 Gun Type
0 = Corona
1 = Tribo
0
C-3 AUX output latency after trigger release (s) 0-100 10
C-4 Pneumatical Control Type
0 = Proportional
1 = Independent
0
C-5 Pneumatical Flow Units
0 = lt/m
1 = Nm3/h
1
C-6 Purge Valve Opt.
0 = Disabled
1 = Enabled
0
C-7 Gun Cable Length (m) 5-25 5
PCF1 Min. Powder Corr. Factor (lt/m) 0 - 50 5
PCF2 Powder Output Corr. Factor 0 - 100 100
Calibration Preferences
Info: Correction Factors should be adjusted from the “Correction Factors Adjustment Table” below.
