PCF-1 Correctional Factor Reference Table
Gun Maximum Powder Output Correction Factor PCF1
Before Correction After Correction
1 PCF1 = 5 lt/min 22 gr. PCF1 = 2 lt/min 13 gr.
2 PCF1 = 5 lt/min 14 gr. PCF1 = 5 lt/min 14 gr.
3 PCF1 = 5 lt/min 3 gr. PCF1 = 15 lt/min 12 gr.
After adjusting the PCF1 Minimum Powder Output Correction Factor, the user can adjust the PCF2 Powder Output Equalization
Factor (%) procedure. This procedure is as follows:
1. On the Main Page, the Total Air Flow should be adjusted to 4,0Nm3/h or 67lt/min.
2. Also the Powder Ration should be adjusted to %80.
3. While on Main Page, Press and hold the B1 interface button for ve (5) seconds to reach the Calibration Page.
After this step, you must use a lter type powder bag to measure the powder output in one (1) minute.
4. Put the powder bag at the tip of the gun.
Info: Before putting the bag on, measure the weight of the bag to make a better calculation. Press the trigger for a whole 60 seconds and
stop the trigger.
5. Press the trigger for a whole 60 seconds and stop the trigger.
6. Release the bag from the tip of the gun and weight it.
7. After measuring all the automatic guns’ output, proceed to the next step.
8. Make the below calculation for all the automatic guns and get the necessary C-9 parameter.
9. Input the calculated parameter on the control unit.
After the input procedure, there will be a similar table like below
PCF-2 Correctional Factor Reference Table
Gun Minimum Powder Output Correction Factor PCF-2
Before Correction After Correction
1 PCF2 = %100 220 gr. PCF2 = %100 220 gr.
2 PCF2 = %100 255 gr. PCF2 = %86 220 gr.
3 PCF2 = %100 275 gr. PCF2 = %80 220 gr.
PCF2
gun
X 100
Minimum Powder Output (g/mn)
Measured Powder Output
gun
(g/mn)
