31
ACCESSOR
Y TYPE
ORDER CODE
PA
RT
#
E-COA
T
Platform Mounting
Kit
B07 ECT004
1
E-COA
T
W
all Mounting
Kit
B07 ECT003
2
E-COA
T
Single Stand
Ki
t
B07 ECT005
3
E-COA
T
Mobile Stand
Kit
B07 ECT001
4
E-COA
T
MultiColor
Ki
t
B07 ECT002
5
