Electronics International CGR-30C - Default Chapter; Table of Contents

Contents
(Page 1 of 3)
Warranty/Agreement-------------------------------------------------------------------------------------- 1A
1.0 System Overview ------------------------------------------------------------------------------------- 2
1.1 System Description --------------------------------------------------------------------------- 4
1.1.1 CGR Display ---------------------------------------------------------------------------- 4
1.1.2 EDC-33P --------------------------------------------------------------------------------- 4
1.1.3 Probes, Transducers and Modules --------------------------------------------------- 4
1.1.4 Wiring & Extension Cables ----------------------------------------------------------- 4
1.2 Operational Overview ------------------------------------------------------------------------------- 5
1.3 Installation Overview
--------------------------------------------------------------------------------- 5
2.0 Hardware Installation -------------------------------------------------------------------------------- 6
2.1 Important Information and Initial Check Out: ------------------------------------------- 8
2.2 Review the "EDC Wiring Work Sheets:" ------------------------------------------------- 9
2.3 Verify you have all the necessary Probes, Modules, Transducers and Cables: ----- 9
2.4 Install the CGR Display: --------------------------------------------------------------------- 9
2.5 Install the Temperature Probes: ------------------------------------------------------------- 10
2.6 Install the Pressure Transducers: ----------------------------------------------------------- 12
2.7 Install the CO Detector, G-Sensor and/or Other Available CGR Options ------- 14
2.8 Install the Shunt: ------------------------------------------------------------------------------ 15
2.9 Install the Fuel Flow Transducer: -------------------------------------------------------- 17
2.10 Install the P-300C Fuel Level Probes (OEM or Experimental) --------------------- 23
2.11 Install the P-300M Fuel Levl Sender: ---------------------------------------------------- 23
2.12 Install the Resistive Fuel Level Module (RFLM-4-X): ------------------------------- 24
2.13 Install the Voice Alarm Control Panel (OEM Only): -------------------------------- 24
2.14 Install the Intensity Control Pot CP-1A (optional): ----------------------------------- 25
2.15 Install the Master Warning (red) and Caution (yellow) Lights: ----------------------- 25
2.16 Install the Interface Circuit for a PWM Backlight System (Optional): --------------
26
2.17 Install the USB-6A (optional): -------------------------------------------------------------- 26
2.18 Install the FM-SC or AC-1 Converter (optional): -------------------------------- 26
2.19 Install any Additional Modules (optional): ----------------------------------------- 26
2.20 Install the EDC-33P: ------------------------------------------------------------------------ 26
3.0 Install the EDC Wire Harnesses and Route Wires ---------------------------------------------- 28
3.1 Attach the three EDC 37-pin wire harnesses to the EDC: ---------------------------- 30
3.2 Connect the EDC Harness to the Temperature Probes: -------------------------------- 30
3.3 Connect the EDC Harness to the Pressure Transdcueres: ----------------------------- 30
3.4 Connect the EDC Harness to the Shunt: -------------------------------------------------- 31
3.5 Connect the EDC Harness to the Fuel Flow Transducer: ----------------------------- 31
3.6 Connect the EDC Harness to the Existing Capacitive Fuel Level System: -------- 31
3.7 Connect the RFLM-4-x Harness to the EDC Connector and to the Resistive
