7.2 Setup-Menu
Menu Description Default
Setup 1/7
Delay Record
Timing (delay) of the recordings (Program 1 or 2 time slots per day for a programmed
number of days)
Nr. Days Enter the number of days on which the time windows (one or both) are performed.
0 = time control (delay) disabled
Example: 30
For a maximum of 30 days, recording is performed during the configured time slot (see
below)
0
T1 Start 1. start time (in 15 minute steps)
Example: 20:30
00:00
T1 Stop 1. stop time (in 15 minute steps)
Example: 00:00
00:00
T2 Start 2. start time (in 15 minute steps)
00:00 = 2. time slot disabled
Example: 04:30
00:00
T2 Stop 2. stop time (in 15 minute steps)
00:00 = 2. time slot disabled
Example: 06:00
00:00
Rec Intervall Interval time between single recordings (in one minute steps)
Example: 3
After a recording at least 3 minutes no new recording is started (triggered)
0
Setup 2/7
Trigger
Trigger settings
Set the trigger mode, that is how a recording is started
TRIG_MODE: Choose trigger mode:
0 = Manual: start and stop recording need manual key input (autom. stop after
2
