Motor supply voltage too low:
− use a shorter extension cable or
extension cable with larger lead
cross section
(≥1.5mm
2
).
− Have power supply checked by a
qualified electrician.
Loss of cutting performance
Saw blade blunt (possibly tempering
marks on blade body):
− replace saw blade (see section
"Maintenance").
Chip build-up in the chip case
No dust collector or one of insufficient
suction capacity connected:
− Connect dust collector or
− increase suction capacity (air speed
≥ 20m/sec at chip ejection tube).
Sliding plate of chip case closed:
− Open sliding plate
15.Technical Specifications
TKHS 315 E/P
2200 WNB
TKHS 315 E/P
2200 W
TKHS 315 E/P
3100 W
TKHS 315 E/P
2800 D
TKHS 315 E/P
4200 D
Voltage 110V / 1~50Hz 230V / 1~50Hz 230V / 1~50Hz 400V / 3~50Hz 400V / 3~50Hz
Nominal current A 23.0 10.6 14.0 4.7 7.5
Fuse protection min. A 1 - 25 (time-lag)1 - 16 (time-lag)1 - 16 (time-lag)3 - 16 (time-lag) 3 - 16 (time-lag)
Degree of protection IP54 IP54 IP54 IP54 IP54
Motor speed min
-1
2700 2800 2800 2800 2800
Motor capacity input capacity P
1
power output P
2
kW
kW
2.5 S6 40%
1.6 S1 100%
2.2 S6 40%
1.5 S1 100%
3.1 S6 40%
2.0S1 100%
2.8S6 40%
1.8 S1 100%
4.2 S6 40%
2.0 S1 100%
Saw blade cutting speed m/s 45 47 47 47 47
Saw blade diameter (outer) mm 315 315 315 315 315
Arbor bore mm 30 30 30 30 30
Depth of cut
with saw blade vertical
saw blade at 45° bevel tilt
mm
mm
0...85
0...53
0...85
0...53
0...85
0...53
0...85
0...53
0...85
0...53
Dimensions length saw table
width saw table
height (saw table)
height (overall)
mm
mm
mm
mm
800
600
850
1150
800
600
850
1150
800
600
850
1150
800
600
850
1150
800
600
850
1150
Weight complete approx. kg 65,0 65,0 66,0 67,0 68,0
Noise emission values according to
DIN 45635
no-load
under load
dB (A)
dB (A)
74.8
90.2
74.8
90.2
74.8
90.2
74.8
90.2
74.8
90.2
