1. Getting to Know Your Saw
1
4
5
6
7
8
9
10
12
11
3
2
1 Suction hose
2 Accessory storage hook
3 Blade tilt lever
4 Twist handle for locking the
blade tilt angle
5 Bevel tilt scale
6 Handwheel for setting the
depth of cut
7 ON/OFF switch with emer-
gency stop
8 Mains connection
9 Sliding plate (on the under-
side)
10 Dust extraction port of chip
case assembly
11 Table insert
12 Saw blade guard with dust
extraction port
