PS 9000 T Series
1000 / 1500 W
Model
PS 9500-06 T PS 9040-60 T PS 9080-60 T
Power regulation
Display: Resolution See section „1.9.5.4. Resolution of the displayed values“
Display: Accuracy
(2
≤0.8%P
Max
≤0.8%P
Max
≤0.8%P
Max
Efciency
(4
~ 93% ~ 92% ~ 92%
Analog interface (optional)
(3
Set value inputs U, I, P
Actual value output U, I
Control signals DC on/off, remote control on/off
Status signals CV, OVP, OT
Galvanic isolation to the device Max. 1500 V
DC
Sample rate of inputs & outputs 500 Hz
Insulation
Output (DC) to enclosure (PE)
DC minus: permanent max. ±400 V
DC plus: permanent max. ±400V + output voltage
Input (AC) to output (DC) Max. 2500 V, short-term
Miscellaneous
Cooling Temperature controlled fan (60 mm), side inlet, rear exhaust
Ambient temperature 0..50°C
Storage temperature -20...70°C
Humidity < 80%, not condensing
Standards EN 61010, EN 61326
Overvoltage category 2
Protection class 1
Pollution degree 2
Operational altitude < 2000 m
Digital interfaces
Built-in (default) 1x USB-B for communication, 1x USB-A
Built-in (optional) 1x LAN for communication
Galvanic isolation from device Max. 1500 V
DC
Terminals
Rear side AC input, analog interface (optional), USB-B, Ethernet (optional)
Front side DC output, USB-A, remote sensing
Dimensions
Enclosure (WxHxD) 92 x 237 x 412 mm
Total (WxHxD) 92 x 239 x min. 461 mm
Weight ~8.5 kg ~8.5 kg ~8.5 kg
Article number 06200449 06200450 06200451
(1Relatedtothenominalvalues,theaccuracydenesthemaximumdeviationbetweenanadjustedvaluesandthetrue(actual)value.
(2 The display error adds to the error of the related actual value on the DC output
(3Fortechnicalspecicationsoftheanaloginterfacesee„3.5.4.4 Analog interface specication“ on page 51
(4 Typical value at 100% output voltage and 100% power
