PS 9000 T Series
3.9 Loading and saving a user prole
The menu “Proles”servestoselectbetweenadefaultproleandupto5userproles.Aproleisacollectionof
allsettingsandsetvalues.Upondelivery,orafterareset,all6proleshavethesamesettingsandallsetvalues
are0.Iftheuserchangessettingsorsetstargetvaluesthenthesecreateaworkingprolewhichcanbesavedto
oneofthe5userproles.Theseprolesorthedefaultonecanthenbeswitched.Thedefaultproleisread-only.
Thepurposeofaproleistoloadasetofsetvalues,settingslimitsandmonitoringthresholdsquicklywithout
havingtoreadjustthese.AsallHMIsettingsaresavedintheprole,includinglanguage,aprolechangecanalso
be accompanied by a change in HMI language.
Oncallingupthemenupageandselectingaprolethemostimportantsettingscanbeseen,butnotchanged.
► How to save the current values and settings (working prole) as a user prole
1. While the DC output is switched off, tap the touch area on
the main screen
2. In the menu page, tap on “Page 2” and then on “Proles”.
3. In the selection screen (see image to the right) choose between user
proles1-5inwhichthesettingsaretobesaved.Theprolewillthenbe
displayed and the values can be checked, but not changed.
4. Tap on touch area “Save/Load”andinthenextscreensavetheuserprole
with touch area “Save”.
► How to load a user prole to work with
1. While the DC output is switched off, tap the touch area on the main screen
2. In the menu page, tap on “Page 2” and then on “Proles”.
3. Intheselectionscreen(seeimagetotheright)choosebetweenuserproles1-5inwhichthesettingsare
tobesaved.Theprolewillthenbedisplayedandthevaluescanbechecked,butnotchanged.
4. Tap on touch area “Save/Load”andinthenextscreenloadtheuserprolewithtoucharea“Load”.
UserprolescanalsobeloadedfromandsavedtoaproperlyformattedUSBstick(seesection1.9.5.5 for details).
► How to load a user prole from USB stick or save to
1. While the DC output is switched off, tap the touch area on the main screen
2. In the menu page, tap on “Page 2” and then on “Proles”.
3. Intheselectionscreen(seeimagetotheright)choosebetweenuserproles1-5inwhichthesettingsare
tobesaved.Theprolewillthenbedisplayedandthevaluescanbechecked,butnotchanged.
4. Tap on touch area “Import/Export”andinthenextscreeneithersavetheproletoUSBstickbytapping
on “Save to USB” or load it from the stick with “Load from USB”.
• When loading a prole from USB stick it will overwrite all previously stored values of
the selected user prole
• The number in the prole le name is not related to the user prole number from which
it once was saved or to which is it going to be loaded
• The selector for picking a prole le to load can only list the rst 10 les in the folder
• Prole les are checked for validity upon load to determine if the stored values match
the device
AfteraprolehasbeenloadedfromUSBstickitdoesn’tbecomeeffectiveautomatically.Likewhenswitching
betweenproles,itrequirestoloadtheuserproleintotheworkingprole.Seeaboveforthesteps.
