ELGA Micra Operators Manual
Page 15 Micra MANU39752 Version 01 – 02/12
10. TECHNICAL SPECIFICATIONS
1
Purication Pack life may be low with feedwater >1400μS/cm
FEEDWATER
Model Micra
SOURCE Potable tap water as detailed below.
Conductivity < 2000µS/cm
1
Hardness <250ppm as CaCO
3
Free Chlorine <0.5ppm Cl
2
Silica <30ppm SiO
2
Fouling Index <10
Iron/Manganese < 0.1ppm Fe/Mn
Organics (Total Organic Carbon) <3ppm TOC
TEMPERATURE 4-40°C (recommended 15-25°C)
FLOWRATE
(maximum requirement at 15ºC)
Up to 72L/h
FEEDWATER PRESSURE
Minimum Inlet Pressure 1bar (15psi)
Maximum Inlet Pressure 2bar (30psi)
2
2
In the situation that the Inlet Pressure >2bar (30psi) add a pressure regulator
CONNECTIONS
Inlet 1/4" OD tube
Outlet 1/4" OD tube
Drain 1/4" OD tube
DIMENSIONS and WEIGHTS
Dimensions
Width 22.5”, Depth 10.3”, Height 15”
Width 505mm, Depth 230mm, Height 335mm
Operational weight
26.5lb
12kg
Installation Floor/ Bench / Wall
ELECTRICAL REQUIREMENTS
Mains input 100-240Vac, 50-60Hz
System control voltage
(not including pumps and UV)
24Vdc
Power consumption (peak demand) 120VA
