ELGA Micra - DI Pack Installation

ELGA Micra Operators Manual
Page 7 Micra MANU39752 Version 01 – 02/12
3) UNSCREW the housing for the Carbon Filter.
4) UNPACK the Carbon Filter from its packaging. PLACE the
Carbon Filter inside the housing and SCREW it back in place.
4.4 DI Pack installation
1) REMOVE a new Purication Cartridge from its packaging.
REMOVE the sealing plugs from the inlet and outlet ports.
WET ‘O’ rings and SLIDE the cartridge into the position.
POSITION cartridge onto spigots at rear and PUSH into unit.
(1)
(2)
