Output Configurations
These depend on setting of Register R8/5
Value 0 3 speed operation (Elgo standard default)
3 speeds selected by relays 1,2 & 3
output 4 sets direction reverse
OUTPUT ST5/ 1 2 3 4
Creep forwards X
Slow forwards X X
Fast forwards X X X
Creep reverse X X
Slow reverse X X X
Fast reverse X X X X
R1 = Run, R2 = Slow & R3 = Fast combined with Run.
If used with 2 speed, R2 or R3 = Fast.
Can also be used with single speed.
Value 1 2 speed operation
Independent outputs forward and reverse
Independent outputs fast and slow
OUTPUT ST5/ 1 2 3 4
Creep forwards X X
Slow forwards
Fast forwards X X
Creep reverse X X
Slow reverse
Fast reverse X X
R1 = Run forwards, R4 = Run reverse, R2 = Creep, R3 = Fast
Value 2 2 speed operation
Speed set by Relays 2 & 3
Direction set by Relay 4
OUTPUT ST5/ 1 2 3 4
Creep forwards X X
Slow forwards
Fast forwards X X
Creep reverse X X X
Slow reverse
Fast reverse X X X
R1 = Positioning (drive inhibit or brake)
R2 = Creep, R3 = Fast (both independent)
