ELGO Electric P8511 Series User Manual

15
Value 3 2 speed operation
Independent outputs for direction and speed
OUTPUT ST5/ 1 2 3 4
Creep forwards X
Slow forwards
Fast forwards X
Creep reverse X
Slow reverse
Fast reverse X
Value 4 3 speed operation
Forwards – 3 Outputs set speeds
Reverse – always fast
Output 4 = reverse
OUTPUT ST5/ 1 2 3 4
Creep forwards X
Slow forwards X X
Fast forwards X X X
Creep reverse X X X X
Slow reverse X X X X
Fast reverse X X X X
Value 5 3 speed operation
Binary coded Outputs 2 & 3 for speed
Output 1 = Forwards, Output 4 = Reverse
OUTPUT ST5/ 1 2 3 4
Creep forwards X X
Slow forwards X X
Fast forwards X X X
Creep reverse X X
Slow reverse X X
Fast reverse X X X
Value 6 3 speed operation
Output 1 = Run forwards, Output 4 = Run reverse
OUTPUT ST5/ 1 2 3 4
Creep forwards X
Slow forwards X X
Fast forwards X X X
Creep reverse X
Slow reverse X X
Fast reverse X X X
