PAR. DESCRIPTION MODEL RANGE VALUE M.U. LEVEL
DISPLAY (folder ‘diS’)
LOC
LOCk. Setpoint edit lock. The parameter programming menu can still be
accessed, and the settings changed, which means also that the status of this
parameter can be changed so as to unlock the keypad. n (0)= no; y (1) = yes.
ALL n/y n flag User/Inst
PS1
Password 1. When enabled (PS1 ≠ 0) it is the password to the ‘User’
parameters (User).
ALL 0...250 0 num User/Inst
PS2
Password 2. When enabled (PS2 ≠ 0) it is the password to the ‘Installer’
parameters (Inst).
ALL 0...250 15 num Inst
ndt
Display values with decimal point. n (0) = no (integers only);
y (1) = yes (displayed with decimal point); int (2) = integer.
ALL n/y/int n num User/Inst
CA1
Calibration 1. Positive or negative temperature value added to the value read by
Pb1, according to the setting of parameter CAI.
NTC/PTC -30.0...30.0 0.0 °C/°F
User/InstPT100-Tc -30.0...30.0 0.0 °C/°F
V/I -30...30 0 num
CAI
Intervention of the offset on display, temperature control or both.
0 = only the temperature shown is modified;
1 = sum with only the temperature used by the controllers and not for the
display, which remains unchanged;
2 = sum with the displayed temperature, which is also used by the regulators.
ALL 0/1/2 2 num Inst
LdL Minimum value that can be displayed by the device.
NTC/PTC -199.9...HdL -50.0 °C/°F
Inst
PT100-Tc -328...HdL -199.9 °C/°F
V/I -199...HdL -199 num
HdL Maximum value that can be displayed by the device.
NTC/PTC LdL...199.9 140.0 °C/°F
InstPT100-Tc LdL...1350 1350 °C/°F
V/I LdL...199 199 num
dro
Select the unit of measurement of probe 1.
• NTC/PTC and PT100-Tc: C (0) = °C, F (1) = °F
• V/I: n (0) = no unit of measure selected,
t (1) = temperature, P (2) = pressure, H (3) = humidity
NTC/PTC C/F C flag
InstPT100-Tc C/F C flag
V/I n/t/P/H n num
