Ellis 9400 - Page 13

13
1.800.383.5547
Figure A – Inserting
Figure C
Figure B – Removing
Drill Chuck and Arbor Attachment
Elevating, Rotating and Clamping the Table
Loosen column clamp
screws before moving
table otherwise
damage will occur.
WARNING:
8407 Column Clamp Screw
8407 Column Clamp Screw
8406 Elevating Handle
8486 Revolving Handle
8649 Chuck
8073 Drift Key
Quill Slot
Align slots
