Ellis 9400 - OVERVIEW OF DRILL PRESS TERMS

23
1.800.383.5547
OVERVIEW OF TERMS
Cover (Belts and Pulleys Cover)
Head Stock
Power Feed Unit
Quill
Morse Taper Bore
Feed Handles
Worktable
Table Clamp Screw
Table Bracket
Column Base
Column ASSY
Column Clamp Screw
Column Clamp Screw
Rack Gear
Shift Handle
Motor
Torque Bolt Range ASSY
