14
Number
Part
Number Name
1 8437 Feed Pulley & Clutch ASSY
2 4938 V-Belt Upper, Power Feed
3 8436 Nut (2)
4 8434 Spindle Pulley
5 8433 Worm Base
6 8432 Spindle Shaft
7 8382 Cover Knob ASSY
8 8431 Cover
9 8430 Spacer
10 8428 Sight Window
11 8429 Spring & Cover
12 8423 Spring Cap
13 8422 Shaft Base
14 8419 Head Stock
15 8418 Gear Shaft
16 8154 Control Bracket
17 4830 VS Control Box (110V)
18 4831 VS Control Box (220V)
19 4819 Red Emergency Stop Button
20 8151 Control Box Base
21 4767 Fwd-Rev. Toggle Switch
22 8417 Turbo Worm Gear
23 8416 Counter Block
24 8415 Quill
25 8414 Worm Cover
26 8413 Thrust Plate
27 8412 Nut
28 8440 Dial (Standard Measure)
29 8439 Handle Hub
30 8411 Spindle
31 4939 V-Belt Lower, Front Drive
32 8495 Middle Sheave ASSY
33 8476 Swivel Base Weldment
34 8081 Set Screw
35 4646 Variable Speed Pulley
Number
Part
Number Name
36 4943 V-Belt, Rear Drive
37 4647 Motor, 2HP (1.5KW)
38 8475 Motor Mounting Plate ASSY
39 8121 Motor Fan Cover
40 8122
Motor Junction Box Cover
(not pictured)
41 8115 Shift Handle
42 8101 Torque Bolt Range ASSY
43 8452 Worm Cover
44 4487 Ball Bearing
45 8461 Bevel Gear
46 8453 Worm, Double Thread
47 8441 Key
48 8454 Shim Plate
49 8455 Turbo Gear
50 8457 Transmission Shaft
51 8458 Gear
52 8459 Transmission Base
53 4487 Ball Bearing
54 8461 Bevel Gear
55 8380 Hub & Pawl ASSY
56 8465 Plate
57 8450 Power Feed Unit ASSY
58 8467 Block
59 8468 Power Feed Label
60 8469 Manual Feed Label
61 8470 Worm Housing
62 4487 Ball Bearing
63 8471 Lock Screw
64 8472 Locking Handle
65 8473 Power Feed Bolt ASSY
66 8383 Thumbscrew ASSY
67 8474 Feed Handle
68 8481 Handle Grip
HEAD ASSEMBLY (For Bearings See Page 17)
PARTS LIST
NOTE: When ordering parts, please provide the serial number located on the Drill Press head.
