9
1.800.383.5547
Spindle RPM
Torque
Range
Position
VS Control Box Frequency – Hz
120 105 90 75 60 45 30 20 15 10
High Speed
1265 1110 950 792 633 473 317 209 156 102
Mid-Range
930 820 705 585 465 350 233 153 115 77
High Torque
570 501 428 358 285 215 143 94 71 46
SPEED & TORQUE RANGE OVERVIEW
HIGH
SPEED
MID-RANGE
TORQUE
HIGH
TORQUE
MUST RUN MOTOR TO SHIFT TORQUE!
R
e
a
d
a
n
d
u
n
d
e
r
s
t
a
n
d
O
w
n
e
r
s
M
a
n
u
a
l
b
e
f
o
r
e
o
p
e
r
a
t
i
n
g
t
h
i
s
m
a
c
h
i
n
e
!
5050-1
8434
Spindle Pulley
8101
Torque Bolt Range ASSY
8115
Shift Handle
4647
Motor
8437 Feed Pulley & Clutch ASSY 8495 Middle Sheave ASSY 4646
Variable
Speed Pulley
SPINDLE SPEED
The motor (#4647) drives the middle sheave (#8495) and the spindle pulley (#8434) by V-Belts. The spindle pulley
drives the spindle and the taper sleeve. The spindle speed is variable by means of the Variable Speed Control Box
and/or with Shift Handle. Forward and reverse rotation of the spindle is selected on the VS Control Box Panel.
If you have any problems, call the factory.
