■CONNECTING TO A COMPUTER
The MX-1 is compliant to uvc (video class) standard. You can transfer the image via USB by
connecting the MX-1 to a computer using the USB3.0 cable (bus power).
①Connect the microB connector terminal of the USB3.0 cable to connector in the
side of the MX-1.
②Connect the typeA terminal of the USB3.0 cable to the USB port of your running computer.
③The MX-1 will be turned on after the connection is established.
■CONNECTING TO A PROJECTOR OR MONITOR
By using the MX-1 CONNECT BOX, you can connect the MX-1 to a projector or monitor
without using a computer.
①Connect a projector or monitor to the MX-1 CONNECT BOX via the HDMI cable or RGB
cable.
②Connect the supplied DC power cable to . Connect the USB plug to the AC adapter.
Then connect it to a wall outlet.
③Connect the MX-1 to the MX-1 CONNECT BOX via the supplied Expansion cable.
④The MX-1 and MX-1 CONNECT BOX will be powered on. （MX-1 of LED：blue）
Caution
・When connecting to the USB2.0 port, the frame rate may be decreased depending on the
output resolution.
・The frame rate may be decreased depending on the computer used.
