Elmo MX-1 User Manual (English)

Other manuals for Elmo MX-1

Questions and Answers:

D
David WilliamsAug 21, 2025
Why is no image displayed on my Elmo MX-1?
- K
  Katherine OsborneAug 21, 2025
  If no image is displayed on your Elmo Digital Presenter, several factors could be the cause. First, check that the AC adapter and power cable are securely reconnected. If you've just turned the power off and back on, wait a few seconds before turning it on again. Ensure the output setting matches the connected cable and that the switch on the side panel is set to the right. Also, confirm that the monitor is on and the input source is correctly set.
R
Randall BushAug 23, 2025
How to fix a too dark image on Elmo MX-1 Digital Presenters?
- K
  Kimberly HodgeAug 23, 2025
  If the image on your Elmo Digital Presenters appears too dark, it might be due to insufficient lighting. To resolve this, set the MX-1 to Brightness mode from the operating panel and adjust the brightness. Alternatively, switch to Zoom mode and turn on the LED lighting with a short press of the button.
C
Charles RiggsAug 25, 2025
Why is the image striped on my Elmo Digital Presenters?
- T
  troymccoyAug 25, 2025
  Striped images on your Elmo Digital Presenters can result from several factors. It may be interference fringes between dots of printed matter and TV scanning lines or CMOS pixels; changing the shooting range of the MX-1 may improve the problem. Vertical stripes on an LCD projector screen can be mitigated by manually adjusting the dot clock from the projector. If the shooting environment is too dark, adjusting the brightness in the Brightness adjustment mode may also help.
H
Hayley NolanAug 27, 2025
Why does the output image resolution change automatically on Elmo MX-1?
- M
  Matthew FarrellAug 27, 2025
  When an HDMI monitor is connected to the MX-1 Elmo Digital Presenter, the output image resolution automatically changes based on information received from the connected monitor.
J
Jennifer MillerAug 27, 2025
What to do if the image is out of focus on Elmo MX-1 Digital Presenters?
- R
  Robert RodriguezAug 28, 2025
  If the image on your Elmo Digital Presenters is out of focus, it might be because the document or object is too close to the lens. Try moving the document or object slightly away from the lens.
K
Kimberly WalkerAug 29, 2025
How to resolve image distortion on Elmo MX-1 Digital Presenters?
- P
  Paula EricksonAug 29, 2025
  If you notice distortion in the image produced by your Elmo Digital Presenter, reducing the resolution of the MX-1 may improve the image quality.
E
evanscindyAug 30, 2025
Why does the image not move on my Elmo Digital Presenters?
- L
  Leslie AllenAug 30, 2025
  If the image on your Elmo Digital Presenter is frozen, the “Freeze” function may be active. This function is selected by pressing the button on the Operating panel of the MX-1. To cancel the freeze status, press the button again.
C
Carol EsparzaSep 1, 2025
How to display 4K image on Elmo MX-1?
- H
  Heather KochSep 1, 2025
  4K image can only be output from a computer connected via the USB. The computer needs to be able to output 4K image. Install Image Mate 4 (which supports the MX-1) to such computer and use it to view 4K image.
F
franklinmurraySep 3, 2025
What to do if the image does not move on my Elmo Digital Presenters?
- A
  Andrew PalmerSep 3, 2025
  If the image is frozen, it may be because the 'Freeze' function is enabled. To solve this, press the button on the operating panel again to cancel the freeze status. If you are using Image Mate 4, cancel the freeze status within the software to resume the live image feed. Also, please reconnect all the cables.
M
mwebsterSep 4, 2025
What to do if the image is too dark on my Elmo Digital Presenters?
- C
  Christopher DavidsonSep 4, 2025
  If the image appears too dark, the lighting may be insufficient. To fix this, press the button on the operating panel to adjust the brightness. Alternatively, press the button to turn on the LED lighting.

Elmo MX-1 Specifications

General

Frame Rate	30 fps
Focus	Auto/Manual
Image Rotation	0°, 90°, 180°, 270°
Brightness Adjustment	Yes
White Balance	Auto / Manual
USB Port	USB 2.0
HDMI Output	Yes
Aperture	f/2.0
Lighting	LED
Compatibility	Windows, macOS
Resolution	1920 x 1080
Connectivity	USB, HDMI
Effective Pixels	2.07 million pixels
Image Effects	Black & White, Negative
External Memory	SD Card
Audio Input	3.5mm jack
Audio Output	3.5mm jack
Image Sensor	1/2.7 inch CMOS
