Elmo OX-1 User Manual

17
➏
SPECIFICATION
◆MAIN CAMERA
Item Specifications
Power source DC5V
Power consumption 2.5W
Outside dimensions W：317mm D：108mm H：375mm(When setup)
W：337mm D：108mm H：54mm(When folded)
Weight Approx. 630g（Main body only）
USB device
USB2.0 TypeB × 1
Power supply：bus power
Lens F=2.0
Frame rate 30fps（max）
Focus working range From lens surface：100mm 〜 ∞
Focus Auto（One-push）
Exposure Auto
Image pick-up
element
1/3.2 inch CMOS 8,000,000 pixels
Effective pixels H：3280, V：2464
Resolution H：1000TVlines or more V：1000TVlines or more
Shooting area 322mm×430mm（Height：359mm） 4：3
◆FUNCTIONAL SPECIFICATION
Item Specifications
Operating
button
IM+C IM4 EIT
Brightness Possible(Set value: -64 to 64, changes every 2
values) Default value: 0
- - ✔ ✔
Image rotation 0°/0°mirror/180°mirror/180° Default setting：0°
（
The image rotation function is not available when the
image freeze function is used.
）
- ✔ ✔ ✔
LED lighting ON/OFF Default setting：OFF ✔ - - -
AF（focus） Manual（One-push） ✔ - - -
Zoom Possible with Image Mate +C／Image Mate 4(IM4)
／ELMO Interactive Toolbox (EIT)
- ✔ ✔ ✔
Image pause - ✔ ✔ ✔
Resolution Possible to change ※1 - - ✔ ✔
Flicker 60Hz / 50Hz（Default setting：60Hz） - - ✔ ✔
Contrast Possible（Set value 0～100） Default value：32 - - ✔ ✔
Hue Possible（Set value -180～180） Default value：0 - - ✔ ✔
Saturation Possible（Set value 0～100） Default value：64 - - ✔ ✔
Gamma Possible（Set value 100～500）
Default value：300
- - ✔ ✔
White balance Auto/manual （Set value 2800～6500）
Default setting：Auto
- - ✔ ✔
Backlight
compensation
ON/OFF
Default setting：OFF
- - ✔ ✔

Elmo OX-1 Specifications

General

Sensor type	CMOS
Image freeze	Yes
Maximum frame rate	30 fps
Optical sensor size	1/3.2 \
Effective sensor resolution	8 MP
Supported graphics resolutions	3264 x 2448
Interface	USB 2.0
USB connector type	USB Type-B
USB 2.0 ports quantity	1
Digital zoom	8 x
Maximum aperture number	2.2
Product color	White
Quantity per pack	1 pc(s)
Operating voltage	5 V
Power supply type	USB
Power consumption (typical)	1.25 W

Weight and Dimensions

Depth	108 mm
Width	317 mm
Height	375 mm
Weight	630 g
Dimensions folded (WxDxH)	337 x 108 x 54 mm
