Why does the remote control not work with my Elmo L-12W Document Camera?
If the remote control for your Elmo Document Camera isn't working, the issue might be due to low battery power. Try replacing the coin battery with a new one. Also, ensure you are using the supplied remote control, as using an incorrect remote can also cause this problem.
What to do if the image is out of focus on Elmo Document Camera?
If the image on your Elmo Document Camera is out of focus, it could be that the document or subject is too close to the lens. Try moving the document slightly away from the lens to see if that improves the focus.
How to brighten a dark image on my Elmo Document Camera?
If the image on your Elmo Document Camera appears too dark, it's likely that the intensity of the lighting is insufficient. You can adjust the brightness by turning on the LED lighting on the camera head.
Why is the image frozen on my Elmo Document Camera?
If the image on your Elmo Document Camera is not moving, the camera image might be set to Pause. Press the Pause button on the operating panel or the remote control again to restart the image.
How to resolve a striped image on my Elmo L-12W?
If the image from your Elmo Document Camera appears striped, this may be due to interference fringes between dots of printed matter and TV scanning lines or CMOS pixels. Changing the shooting range may improve the problem. Also, if vertical stripes appear on an LCD projector image, manually adjusting the dot clock at the projector side may improve the problem.
Why does the output image resolution change automatically on my Elmo L-12W Document Camera?
When an HDMI monitor is connected to your Elmo Document Camera, the output image resolution may automatically change based on information from the connected monitor.
Why is there no image displayed from the USB on my Elmo Document Camera?
If no image is displayed from the USB on your Elmo Document Camera, the product may be in Play mode. Change the output image to the camera image.
What causes the UVC image to fail on my Elmo Document Camera?
If the UVC image fails to be output from your Elmo Document Camera, try disconnecting the USB cable, restarting the software, and then connecting the USB cable again. Additionally, contact the software vendor to ensure that the software you are using supports MJPEG.
What to do if images on the SD card or USB flash drive are not displayed on my Elmo L-12W?
If images on the SD card or USB flash drive are not displayed on your Elmo Document Camera, remove the SD card or USB flash drive, wait a few seconds, and then reinsert it.
Why can't I perform operations after inserting the SD card/ USB flash drive in my Elmo L-12W Document Camera?
If operations cannot be performed after inserting the SD card or USB flash drive into your Elmo Document Camera, the SD card or USB flash drive may not be read correctly. Use the SD card or USB flash drive after formatting it using a computer.
General| AC input voltage | 100 - 240 V |
|---|---|
| Operating voltage | 12 V |
| Power supply type | DC |
| Power consumption (typical) | 5 W |
| Interface | USB 2.0 |
| DC-in jack | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| USB connector type | USB Type-A, USB Type-B |
| VGA (D-Sub) input ports | 1 |
| Lamp type | LED |
| Product color | White |
| Image formats supported | JPG |
| Maximum operating distance | 0.2 m |
| Compatible memory cards | SD |
| Sensor type | CMOS |
| Maximum frame rate | 30 fps |
| Effective sensor resolution | 6.7 MP |
| Supported graphics resolutions | 2992 x 2244, 3264 x 2448 |
| Digital zoom | 16 x |
| Optical zoom | 12 x |
| Shooting area (WxD) | 470 x 260 mm |
| Maximum focal length (f) | 3.6 mm |
| Quantity per pack | 1 pc(s) |
Weight and Dimensions| Depth | 377 mm |
|---|---|
| Width | 349 mm |
| Height | 432 mm |
| Weight | 3000 g |
| Dimensions folded (WxDxH) | 195 x 294 x 475 mm |
Covers safety, cleaning, environment, placement, and ventilation guidelines.
Addresses power sources, grounding, lightning, object entry, and overloading.
Details servicing requirements, damage, parts, and heat considerations.
Covers product usage, environment, cleaning, and handling.
Provides guidelines for media storage, battery, audio, and copyright.
Lists all accessories and items included with the product.
Details part names and main components of the document camera.
Explains the function of each button on the operating panel.
Describes all output and input ports located on the rear panel.
Provides instructions on how to connect via RGB and USB.
Describes the ports and features found on the side panel.
Covers remote control preparation, usage, and IR signal reception.
Details powering the device on/off and initial destination selection.
Explains the start screen, tabs, and menu operations.
Instructions for adjusting image size using the zoom dial and buttons.
Guides on how to adjust the image brightness.
Covers system settings, WiFi, and Ethernet configurations.
Details camera settings like resolution, angle, volume, and flicker.
Instructions for recording images and videos to external media.
How to view recorded lists, full-screen images, and videos.
Details on UVC streaming and connecting to a computer via USB.
Covers connection, basic operations, and calibration with a portable IWB.
Instructions for viewing digital documents and using split screen.
How to use the QR code reader and access the internet via browser.
Covers wireless display via Miracast and using the timer function.
Instructions for using the device with a microscope for enlarged images.
Troubleshooting common errors with media playback and image capture.
Addresses errors related to internet connection and content playback.
Resolving problems with no image, output changes, USB, focus, and darkness.
Addressing striped images, remote control, software errors, and performance.
Details on power, dimensions, ports, lens, and resolution.
Information regarding trademarks and software licenses.
