Non-Measured Currents
The Non-measured Current section helps to configure calculated current channels.
There are two calculation options & they differ for:
 WYE Network,
 DELTA & Single Split Phase Network
CONFIGURING CALCULATED CURRENT CHANNELS FOR WYE NETWORK
 Ensure the Power Configuration coincides with your Network
 In th e Non-Measured Currents section, sele ct t he ap plicable p hase t o be
calculated:
Calculation is based on Kirchhoff’s laws - everything that comes in must go
out, in order for the calculation of one of the current line to be based on
the other measured lines in stead of m easuring it. For ex ample w hen L
x
is
Absent it is being calculated using the other lines instead of measuring it.
Or the ne utral c urrent I
N
could b e o ptionally c alculated f rom t he su m o f
three-phase currents, or alternatively, measured by the I
4
CONFIGURING CALCULATED CURRENT CHANNELS FOR DELTA &
SINGLE SPLIT PHASE NETWORK
current channel.
 Ensure the Power Configuration coincides with your Network
 In the Non-Measured Current section, select the applicable phase to be
missed:
