Connect Power Over Ethernet
PoE is a standard f or feeding D C power to the R TU using the network LA N cable
without th e ne ed f or a dditional e xternal p ower. T he G4 K c ontains 2 p orts tha t
support PoE:
The LAN1 Port can receive PoE supply for the G4K unit from a remote
source, thus enabling the BLACKBOX to operate. I t is suggested that
the LA N1 P oE b e us ed a s an alternative b ackup p ower s ource. T o
activate t his P oE o ption, c onnect a n R J45 j ack w ith PoE to the
marked LAN1 PoE In on the CPU module.
The LAN2/LCD Port has P oE o ut cap ability f or s upplying p ower t o
other de vices. T he L AN2/LCD por t c an s upply pow er f or t he E lspec
G4100 Display unit. To activate this PoE option, connect an RJ45 jack
to t he p ort m arked LA N2/LCD P oE O ut o n the C PU m odule,
connecting th e o ther e nd o f th e R J45 j ack to the G4100 RDU.
Procedure:
Connect a LAN to the indicated ports on the G4K / PoE Injector / G4100:
