Waveforms
The Waveform page displays the actual Voltage & Current waveforms monitored by
your G4K BLACKBOX Unit.
NOTE NOTE NOTE
In order to display the Phasor graph, ensure that you install the ActiveX plug-in
from G igasoft (downloadable either f rom Elspec's W ebsite's Support Section or
alternatively ca n b e in stalled d irectly f rom y our BLACKBOX C D). Y ou w ill
receive the following error message if the program is not installed:
For Internet Explorer 8/9 Users: Once y ou h ave in stalled G igasoft, e nsure
that the Internet Explorer is running in Compatibility View:
OPEN THE WAVEFORMS WINDOW
Access your G4K Unit via the Web Interface select Monitoring
Waveforms:
