VOLTAGE FREQUENCIES
 Frequency compliance is b ased o n s tatistics: N, N 1 & N 2. Fr equency
measurement interval is 10 sec in an entire observation window of 1 week. N -
amount o f in tervals. N 1 - intervals f requency ex ceeded [ +1.00%,-1.00%] f rom
nominal freq. N 2 - intervals frequency exceeded [+4.00%,-6.00%] fr om n ominal
freq. N 1 & N2 in crement only if v alid v oltage i nside n ominal b oundary of
[+15.0%,-15.0%]. Compliance if both N/N1 >= 95. 0% of time and N/N2 >= 100.0%
of time. Intervals with voltage interruption are discarded. Intervals with DIPS or
Over voltage are discarded.
SUPPLY VOLTAGE DIPS
 DIP i s a v oltage dr op of m ore t han 1 0.0% f rom N ominal (bu t no m ore t han
100.0%, and deactivate on 8.0%) DIP min time is 10 ms and max time of 1 min.
DIP events are counted per all phases combined within observation window of 1
week. Total events (N) allowed is: 20.
