The table outlines the sections' Parameters including Definition:
PARAMETER DEFINITION
Frequency Frequency – 10 seconds averaging
Average
150/180 Cycles
Average M easurements at an aggregation of 1 50/180 cy cles
(~3seconds)
Average 10 Min.
Average Measurements at an aggregation of 10 minutes
Average 2 Hours
Average Measurements at an aggregation of 2 hours
Under Deviation
150/180 Cycles
Displays how much lower the Average RMS Voltage is than the
Reference V oltage at an aggregation o f 1 50/180 cy cles
(~3seconds)
U
nder D eviation
10 Min.
Displays how much lower the Average RMS Voltage is than the
Reference Voltage at an aggregation of 10 minutes
Under Deviation
2 Hours
Displays how much lower the Average RMS Voltage is than the
Reference Voltage at an aggregation of 2 hours
Over D eviation
150/180 Cycles
Displays how much higher the Average RMS Voltage is than the
Reference V oltage at an aggregation o f 1 50/180 cy cles
(~3seconds)
Over D eviation
10 Min.
Displays how much higher the Average RMS Voltage is than the
Reference Voltage at an aggregation of 10 minutes
Over D eviation
2 Hours
Displays how much higher the Average RMS Voltage is than the
Reference Voltage at an aggregation of 2 hours
Unbalance
150/180 Cycles
The S upply V oltage Unbalance is E valuated U sing t h
e M ethod
of Symmetrical Components in Accordance with IEC61000-4-30
This en try d isplays t he A verage Maximu
m/Minimum
Unbalanced V alues at a n ag gregation o f 1 50/180 cy cles
(~3seconds)
Unbalance 1 0
Min.
This en try d isplays t he A verage Maximum/Minimum
Unbalanced Values at an aggregation of 10 minutes
Unbalance 2
Hours
This en try d isplays t he A verage Maximum/Mini
mum
Unbalanced Values at an aggregation of 2 hours
