Elstat ems55advanced User Manual

saving
temperature
disable
on if the saving mode temperature is disabled.
The controller maintains ready mode temperature at all times.
red
motion on when motion is detected. red
Push buttons:
button name function
defrost starts a defrost cycle.
set selects menu options and scrolls through the parameters.
up increases the parameter values.
down
scrolls down menus, decreases parameter values, and can-
cels alarms.
2.4 environmental ratings
The table below details the general characteristics of ems55 series controllers.
characteristic value
IP rating IPX5
maximum operating temperature 55
o
C (131
o
)
minimum operating temperature 0
o
C (32
o
F)
housing material black polycarbonate
2.5 ems55 series relay ratings
The table below details the relay ratings of ems55advanced and ems55Radvanced controllers.
relay
maximum IEC rating
@100-240VAC
maximum UL ratings
@ 120VAC
compressor 10(10)A, p.f. 0.6 16 FLA, 96 LRA
lights 4(4)A, p.f. 0.6 120VAC, 60Hz, 250W ballast
evaporator
fan
4(4)A, p.f. 0.6 4.4 FLA, 13.1 LRA
2.6 ems55advanced and ems55Radvanced wiring diagram
The wiring diagrams for the ems55advancedand ems55Radvanced are shown below.
ems55advanced and ems55Radvanced / General Use
10 of 84
