7.1.1 DIP Switch 1
This switch is to set the modem configuration:
ON, RT/CPE: DSL modem acts as Remote type / Customer
premise equipment side (slave).
OFF, OT/CO: DSL modem acts as Office type / Central office side
(master).
7.1.2 DIP Switch 2
This switch is to set the data transmission mode:
ON, Fast mode: Direct data transmitting with latency less than 1
ms.
OFF, Interleave mode: Provides communication protection for up to
250 ms impulse noise with latency less than 6 ms.
7.1.3 DIP Switch 3
This switch is to set the Band plan:
ON, 998 ISDN: DSL modem acts as per 998 ISDN band plan.
OFF, 997 symmetric ISDN: DSL modem acts as per 997 symmetric
band plan.
Please Note!
The setting of this switch must be the opposite as on the
modem on the other side of the communication line.
This switch is only relevant if this modem is the master
modem. See Chapter 7.1.1 - DIP Switch 1 (p.23)
This switch is only relevant if this modem is the master
modem. See Chapter 7.1.1 - DIP Switch 1 (p.23)
