ELTRA ON-900 User Manual

Copyright  2005 by ELTRA GmbH Germany – January 2005 – Operation Manual ON-900
1.2-1
1.2 Front panel illustration
1 Current meter
11 Dust trap
2 Furnace inlet flow
12 Carrier gas pressure gauge
3 Analytical flow (controlled)
13 Compressed air gauge
4 Purge flow regulator
14 Copper oxide catalyst
5 Analysis flow regulator
15 Catalyst furnace
6 Sample drop
16 Mains switch
7 Crucible pedestal
17 Carrier gas pre-cleaning
8 Pneumatic lift
18 CO
R
2
R
/H
R
2
R
O - trap
9 Upper furnace part
19 IR-cell purge pre-cleaning
10 Lower furnace part
100
50
10
130
0
2
1
ON 900
O x yg e n N i t ro g e n De t e rmi na t or
16
15
11
12
13
14
2
3
5
4
A
10
5
4
3
2
0
1
VOLTCRAFT
6
10
8
7
17
19
18
1
9
