Instruction Manual V 1.00.7 30 / 33
Only original replacement parts and accessories are to be used.
Do not continue to use the instrument in the event of mechanical damage occurring. The plastic housing also performs insu-
lating and protective functions, which are only assured as long as it is in its original condition. A damaged instrument should
be returned without delay to a EM Test service centre.
9.4 esd NX30 system error messages
Nr.
Text
Explanation
Action
006
INTERLOCK OPEN
The "Interlock-circuit" is open.
Press "Interlock Reset" button, or
close the interlock circuit at the
back of the base unit.
115
EUT FAILURE
The connected EUT has signaled a
fault.
EUT input has been activated. Re-
set EUT first and then press return
on screen.
125
HV SUPPLY
TIMEOUT
The HV capacitor in the pulse
network cannot be loaded in the
specified time.
HV voltage module has detected
some losses. Switch off the base
station wait for 10 s, switch on
again.
126
HV HOLD
TIMEOUT
Unit stops after 30 s without dis-
charge.
Press return on screen. Restart the
test.
127
HV FAULT
An internal fault on the processor
board has been detected.
Switch off the base station wait for
10 s, switch on again and continue
testing. If error persists, contact
your nearest EM Test service
centre.
129
A FIELD IS
SELECTED
The "Run" or the "HV-on" key has
been pressed although an operator
field is still selected.
Finish the input in the operator
field and then start with "Run".
201
HV INTERNAL DISCHARGE
During test, an internal discharge
has been detected.
Press return on screen and trigger
again. If error persists, contact
your nearest EM Test service
centre.
202
BATTERY EMPTY
The battery is low and needs to be
charged.
Recharge battery with the original
power supply.
210
CALIBRATION
FAILED
HV module can not reach the max.
voltage during calibration proce-
dure.
The voltage can be selected to the
displayed maximum value. Contact
you nearest EM Test service cen-
tre.
211
FAULT DETECTED
The software has found erroneous
behaviour during generation of the
pulse.
Stop the test. Switch off the base
station wait for 10 s, switch on
again and continue testing. If error
persists, contact your nearest EM
Test service centre.
217
VOLTAGE TOO HIGH
The selected value is too high.
Reduce the voltage level.
247
HV TRAFO TOO HOT
NTC resistor too hot after endur-
ance runs.
Power off the esd NX30 and wait
about 1 h.
9.5 Disposal
The following list shows the principal materials used in the construction of the esd NX30. The relevant national regulations
are to be observed when disposing of the instrument.
Component material listing
Pistol housing:
ABS
Base station front panel:
ABS
Base station housing
Galvanized steel, lacquered
Circuit boards:
Epoxi with SMD components
LCD display and touch-panel:
Glass
HV module:
Polyurethane potting compound with electronic network
components and copper wire
HV relay:
Div. metals, ceramic, div. insulating materials
Discharge tip:
Brass, plastics
Battery
(esd NX30 only)
Nickel-metal hydride
Power supply:
ABS housing with transformer and circuit board with electr.
components
Carrying case:
(esd NX30 only)
Aluminum and polyethylene
Pistol stand:
ABS
