10 TECHNICAL SPECIFICATIONS
Description:
Compact ESD simulator with microprocessor controller, large-
surface touch-sensitive LC-display, built-in HV-relay for contact-
discharges, built-in bleed off
Pulse data:
Conforms to IEC / EN 61000-4-2 and ISO 10605, with exchangea-
ble networks for other standards
Pulse network standard:
150 pF / 330 Ω as per IEC, exchangeable networks for other stand-
ards as accessories
Range R = 0 Ω ... 20 kΩ
Range C = 50 ... 2000 pF
Air-discharge voltage:
200 V ... 30 kV (in 100 V steps)
Tolerance < ± 5% (typical 2%, 1 ... 30 kV)
Contact-discharge voltage:
200 V ... 30 kV (in 100 V steps)
Tolerance < ± 5% (typical 2%, 1 ... 30 kV)
Discharge Tip:
Air (ball) and contact (point) as per IEC, exchangeable via threaded
connection
Pulse detection:
Indicated by the "kV" symbol being displayed inverse, also acousti-
cally in the "single" operating mode
Holding time:
> 5 s
Charge resistor:
> 50 MΩ
Triggering:
Trigger button in handgrip or via remote control input
Instrument operation:
Via touch panel and microprocessor
Discharge modes:
Air-discharge / Contact-discharge
Polarity:
Positive, negative and automatic change
Operating modes:
Single / Repetitive / Random T
(see section "Repetition") Pulse counter 0 ... 9999
Preselect counter 0 ... 9999
Continuous operation
Repetition:
0.5, 1, 5, 10, 20, 25 Hz (air)
0.5, 1, 5, 10, 20 Hz (contact)
or in 1 Hz steps
Random
EUT discharge (bleed OFF mode) Free adjustable 0.04 to 300 s in
0.01 s steps
Discharge voltage:
Preprogrammed levels (IEC / EN and ISO standards)
Auto-shut-off:
After 15 minutes idle time (without loss of the test parameters)
Display:
Large LCD panel showing: Discharge voltage Breakdown voltage
Polarity Air- / Contact-discharge Counter / preselect counter content
Battery state monitor
Weight:
esd NX30: 14 kg (30 lbs) approx.
Dimensions
Base Station: (W)170mm x (D)360mm x (H)140mm
Discharge Pistol: (W)85mm x (D)270mm x (H)260mm
Ambient conditions:
Operating +5° ... +40°C 20 ... 80% r.h. (non-condensing)
68 ... 106 kPa
Power supply:
Input: 100 – 250 V / 50 – 60 Hz / 1 A Output: DC 24 V / 2.3 A
Dimensions
Base Station: (W)170mm x (D)360mm x (H)140mm
Discharge gun: (W)85mm x (D)270mm x (H)260mm
EM TEST (Switzerland) GmbH
Sternenhofstrasse 15
4153 Reinach BL1
Switzerland
Phone : +41 61 717 91 91
Fax : +41 61 717 91 99
URL : http://www.emtest.com
Copyright © 2018 EM TEST (Switzerland) GmbH
All right reserved.
Specifications subject to change
