Installation
Page 19
The table below lists the function of each colour coded wire for reference.
Table 2 Colour coding of wires in the accessory cable
The AIS transceiver is designed to operate at voltages from 9.6-31.2V,
however for optimum performance we would recommend maintaining the
voltage range at 12-24V.
Wire
colour
Description Function
Red Power in + Power supply connections
Black Power in -
Light
Green
Switch connection External switch connections for
silent mode
Orange Switch connection
Brown NMEA 0183 port 1 TX+ High speed NMEA 0183 output
(38,400baud) intended for connec-
tion to chart plottersBlue NMEA 0183 port 1TX-
White NMEA 0183 port 1 RX+
Green NMEA 0183 port 1 RX-
Purple NMEA 0183 port 2 TX+ Low speed NMEA port
(4,800baud) intended for connec-
tion to other NMEA 0183 compati-
ble sensors for multiplexing of data
to the chart plotter
Pink NMEA 0183 port 2TX-
Grey NMEA 0183 port 2 RX+
Yellow NMEA 0183 port 2 RX-
Please check your wiring very carefully before applying power
to the product. Failure to wire the product correctly could result
in permanent damage.
