eMachines EL1700 - Main Unit Disassembly Overview

Chapter 3 25
Main Unit Disassembly
NOTE: VGA card and TV tunder card are not available on this model. There are no expension slots on the
main board.
Screw List
Screw Part No.
A #6-32 L5 BZN 86.00J07.B60
B M3xL5 BZN 86.1A324.5R0
C #6-32 L6 NI 86.00J44.C60
MAIN UNIT
FRONT BEZEL
MAIN UNIT DISASSEMBLY
SIDE PANEL
CPU
Ax2
HEAT SINK FAN
ASSEMBLY
POWER SUPPLY
MEMORY MODULES
VGA CARD
OPTICAL DISK DRIVE
HDD-ODD BRACKET
Cx1
HDD MODULE
HDD
Dx4
Ax3, Cx1
Ex1
FRONT I/O AND
CARD READER BOARD
BRACKET
MAINBOARD
Dx2
Bx1, Cx6
FRONT I/O BOARD
CARD READER
BOARD
Cx2
Cx2
Bx1
TV TUNER CARD
Ex1
LED BRACKET
Cx1
POWER SWITCH AND
LED CABLES
