Chapter 3 37
10. Remove the HDD module.
a. Remove the four screws (D) that secure the HDD module to the HDD bracket.
b. Slide the HDD out of the bracket.
Screw (Quantity) Color Torque Part No.
#6-32*3/16 NI (4) Silver 5.5 to 6.5 kgf-cm 86.5A5B6.012
