44 Chapter 3
13. Remove the front I/O board.
a. Remove the two screws (C) that secure the I/O board to the bracket.
b. Pull the I/O board out of the bracket.
Screw (Quantity) Color Torque Part No.
#6-32 L6 BZN (2) Silver 3.5 to 4.5 kgf-cm 86.00J44.C60
