4 iMX OEM Carrier Board Design
This chapter contains information about the peripherals and general design of the iMX OEM Carrier
Board and how to set the different jumpers on the board. The schematic can be downloaded in pdf
format from the support page, and is recommended to have printed out while reading this chapter.
Section naming begins with SPx, which is short for Schematic Page x.
The picture below gives an overview of the iMX OEM Carrier Board design.
Figure 10 – iMX OEM Carrier Board, rev B1, Overview
4.1 Modifications to iMX OEM Carrier Board
The iMX OEM Carrier Board has been designed to be flexible. Most options can be controlled via
jumpers but some options might need soldering.
Note that modifications to the board are done at own risk and void all warranties.
OEM Board
Connector
SD
Interface
Audio
Interface
Ethernet
Interface
USB Host
Interface
USB OTG
Interface
UART-to-USB
Interface
Wakeup push-button
Reset push-button
Power Supply
Input
Expansion Connectors
CAN
Interface
User
LEDs
M.2
Connector
On/Off push-button
ISP Enable push-button
Debug
Connectors
