4.17 Usage of CPU Pins
Almost all pins of the i.MX RT1062 MCU are directly available on the SODIMM expansion connector.
In a few cases are pins used for dedicated functionality like the Ethernet interface, EcoXiP interface
and on-board SDRAM. These pins are not available on the SODIMM expansion connector. The table
below lists all pins and their possible restrictions.
Before using a signal, make sure usage does not collide with functions on the iMX OEM Carrier Board.
iMX OEM Carrier Board
signal name
iMX RT1062 OEM
Board signal name
Usage
JTAG_DBGEN-JTAG_MOD
GPIO_AD_B0_08
Signal is pulled low on the iMX OEM Carrier Board.
JTAG_TCK
GPIO_AD_B0_07
Connects to Arm/Cortex debug connectors.
JTAG_TRST
GPIO_AD_B0_11
Connects to Arm/Cortex debug connectors.
Also function as interrupt signal from capacitive
touch panel controller.
JTAG_TMS
GPIO_AD_B0_06
Connects to Arm/Cortex debug connectors.
JTAG_TDI
GPIO_AD_B0_09
Connects to Arm/Cortex debug connectors.
Used as reset signal for Ethernet-PHY on the iMX
RT10x2 OEM board.
Signal also connected to LED6 on the iMX OEM
Carrier Board.
JTAG_TDO
GPIO_AD_B0_10
Connects to Arm/Cortex debug connectors.
Uses ad interrupt signal for Ethernet-PHY on the
iMX RT10x2 OEM board.
GPIO0-LCDIF_PWREN
GPIO_AD_B0_04
No special usage on iMX OEM Carrier Board
GPIO2-LCDIF_CLK
GPIO_B0_00
Parallel RGB LCD interface - LPC Pixel Clock
GPIO3-LCDIF_VSYNC
GPIO_B0_03
Parallel RGB LCD interface - LPC VSYNC
GPIO4-LCDIF_ENABLE
GPIO_B0_01
Parallel RGB LCD interface - LPC Data Enable
GPIO5-LCDIF_HSYNC
GPIO_B0_02
Parallel RGB LCD interface - LPC HSYNC
GPIO6-LCDIF_D12
GPIO_B1_00
Parallel RGB LCD interface - Red4 bit
GPIO7-LCDIF_D13
GPIO_B1_01
Parallel RGB LCD interface - Red5 bit
GPIO8-LCDIF_D14
GPIO_B1_02
Parallel RGB LCD interface - Red6 bit
GPIO9-LCDIF_D15
GPIO_B1_03
Parallel RGB LCD interface - Red7 bit
USBA-DP/DM
OTG1-DP/DM
Connects to a USB OTG interface
USBB-DP/DM
OTG2-DP/DM
Connects to a USB Host interface
GPIO_B0_15-BOOT_CFG2[3]-
LCDIF_D11
GPIO_B0_15
Parallel RGB LCD interface - Red3 bit
GPIO_B0_04-BOOT_CFG1[0]-
LCDIF_D0
GPIO_B0_04
Parallel RGB LCD interface - Blue3 bit
GPIO_AD_B0_15-
FLEXCAN2_RX
GPIO_AD_B0_15
Connects to RD on CAN transceiver
